Reducer – Stamped (Insulated)

Product Number

Enquire

Specification

Dimension

Specs D1 D2 d1 d2 L kg
100/80 100 132 78 110 65 0.28
125/80 125 157 78 110 80 0.39
160/80 160 192 78 110 95 0.54
125/100 125 157 98 130 54 0.36
160/100 160 192 98 130 77 0.51
180/100 180 212 98 130 88 0.64
200/100 200 232 98 130 102 0.77
160/125 160 192 123 155 69 0.52
180/125 180 212 123 155 85 0.6
200/125 200 232 123 155 90 0.68
160/150 160 192 148 180 65 0.6
180/160 180 212 158 190 74 0.61
200/160 200 232 158 190 66 0.62
200/180 200 232 178 210 57 0.58
Note:
